Product Summary

Product Summary

The XC4VLX100-10FF1513C is the newest generation FPGA from Xilinx. The innovative Advanced Silicon Modular Block or ASMBL; column-based architecture is unique in the programmable logic industry. Virtex-4 FPGAs contain three families (platforms): LX, FX, and SX. Choice and feature combinations are offered for all complex applications. A wide array of hard-IP core blocks complete the system solution.

Parametrics

Absolute maximum ratings: (1)Supply voltage relative to GND: –0.5 to +7.0 V; (2)Supply voltage relative to GND: –0.5 to +12.5 V; (3)Input voltage relative to GND: –0.5 to VCC +0.5 V; (4)Voltage applied to High-Z output: –0.5 to VCC +0.5 V; (5)Storage temperature (ambient): –65 to +150 ℃; (6)Maximum soldering temperature (10s @ 1/16 in.): +260 ℃; (7)Junction temperature: Ceramic: +150 ℃, Plastic: +125 ℃.

Features

Features: (1)Flexible Logic Resources; (2)Built-in System Monitor (voltage/temp. measurement); (3)10-bit, 200kSPS A/D Converter (ADC); (4)Secure Chip AES Bitstream Encryption; (5)90-nm copper CMOS process; (6)1.2V core voltage; (7)Flip-Chip Packaging; (8)RocketIO 622 Mb/s to 11.1 Gb/s Multi-Gigabit Transceivers (MGT) (FX only); (9)IBM PowerPC RISC Processor Core (FX only).
